The MR Series from Ledman has one of the finest pixel pitches available in the rental market today. With a pitch as low as 1.28mm, the MR Series makes 4k and even 8k displays possible in relatively small overall sizes.
With resolution matching a 75” HD TV, these panels make seamless superfine resolution large and freeform displays possible.
The MR Series is built with COB technology (Chip On Board) which is more robust than traditional surface mount LED’s as they are directly bonded to the circuit board. Furthermore, the LED’s are encased in a resin coating making the panels very durable and very smooth making lines between panels almost impossible to distinguish.
- COB Technology
- Pixel Pitch 1.28mm to 1.9mm
- Front & Rear Service
- Easy stack or fly installation
- Moisture and impact resistant
- 16:9 aspect ratio
SPECIFICATIONS
Model | MR1.2 | MR1.5 | MR1.9 |
|---|---|---|---|
| Pixel Pitch (mm) | 1.28 | 1.58 | 1.9 |
| Size (mm) | 608*342*80 | ||
| Pixel (dot) | 480*270 | 384*216 | 320*180 |
| Material | Die cast Aluminum | Die cast Aluminum | Die cast Aluminum |
| Weight (kg) | 8 | 8 | 8 |
| Brightness(nit) | 600 | ||
| Gray scale (bit) | 13 | 13 | 14 |
| Refresh rate(Hz) | 3000 | 3000 | 3840 |
| Power Max./Avg. (W/㎡) | 450/150 | 450/150 | 450/150 |
| Installation/Maintenance | Front & Rear | Front & Rear | Front & Rear |
| Certification | CE ETL FCC RoHS | CE ETL FCC RoHS | CE ETL FCC RoHS |
